CHECKING RADIATOR COOLANT
The radiator is equipped with the
reservoir tank which supplies cool-
ant to the radiator when the coolant
level in the radiator is low. Therefore,
check the coolant level in the reser-
voir tank. When the level is between
the marks "FULL" and "LOW," it is
normal. If the coolant level is below
the mark "LOW," add water to the
level between the marks "LOW" and
"FULL." Do not overll.
(1) Reservoir Tank
(A) Full (B) Low
Coolant Capacity
8.5 L
TRANSMISSION CASE OIL
INSPECTION
When unscrewing the inspection
bolt (M8), oil owing out of the hole
means that the oil level is proper.
If oil is insufficient, add oil through
the ller hole using a funnel.
(1) Oil Filling Hole (2) Inspection Bolt
(3) Drain Plug
