REAPING / THRESHING CLUTCH LEVER
(1) Reaping Clutch Lever
(2) Threshing Clutch Lever
(A) ON (B) OFF
This lever is used to enable reaping
and threshing operation.
•
A: Reaping/Threshing ON (Reaping
and threshing units in operation)
•
B:
Reaping/Threshing OFF (Reaping
and threshing units stopped)
(1) Main shift lever
(A) Up (
) (B) Down ( )
1. This is used to lift or lower the reel.
2. Press the " " section of the switch
to lift the reel.
3. Press the " " section of the switch
to lower the reel.
A
1
B
A
1
B
cf1O415B
2
B
A
1
2
B
A
1
cf1O414A
Before operating the reap-
ing/threshing clutch lever,
make sure that there is no one
around the combine harvester.
Especially, when moving the
reaping/threshing clutch lever
f
rom the ON position to the
OFF position, the reaping/
threshing unit may turn slight-
ly, becoming a possible dan-
ger to people around. Make
sure that no one is around be-
fore operating the lever.
•
CAUTION
MANUAL FEEDING DEPTH CON-
TROL SWITCH
