If reaping dry crops with the dis-
charge control plate placed at the
highest position, the auger can be
clogged. In this condition, adjust the
discharge control plate to the low-
est position. When reaping crops
with high moisture content and low
uidity (other than wheat), adjust the
discharge control plate to the highest
position to prevent overow.
1. Open the grain tank.
2. Adjust the position of the dis-
charge control plates on the front
and back sides of the grain tank.
(1) Loosen the nut (2).
(2) Set the discharge control
plates to the highest or lowest
position.
(3) Tighten the nut (2).
