2
1
2
22
1
11
cf1O729a
(1) Clean-out Cover (2) Wing Bolt
(A) Left (B) Right
A
B
(1) Sieve Case Auxiliary Plate 2 (2) Nut
(3) Sieve Case
(A) Left (B) Right
(C) Adjust
A
3
C
22
2
2
3
C
cf1O772a
B
1
11
C
C
3
3
cf1O773a
1. Remove the left covers (3 & 4) of
the threshing unit and open the
grain tank.
2. Remove the clean-out covers
from the left and right plates of the
threshing unit.
3. Loosen the nut and move the
sieve case auxiliary plate 2 toward
the back of the vehicle body.
4. Tighten the nut.
