DAELIM DAYSTAR Service Manual

13-4
Front Wheel/Front Fork/Steering
Assembly
● Install the handle into the top bridge
connecting hole.
● Tighten the handle washer and nut.
Torque: 2.6kgf-m(26N.m)
● Install the master cylinder into the handle bar
with the “UP” mark on the holder facing up.
● Align the mating surface of the master cylinder
and holder with the punch mark on the handle
bar.
● Tighten the upper socket bolt first then tighten
the lower socket bolt.
●
When removing L. handle grip or R. handle grip
from the Throttle pipe, clean them preventing
the L. handle and throttle pipe attachment part of
handle grip with molybdenum.
● After 3-5 minutes, install the grip. Install the
grip with turning according to user’s manual
attached on adhesives.
• After attaching, leave it over 1hour until drying
the adhesives.
!
CAUTION
△
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting HoleTop Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Top Bridge Connecting Hole
Nut
Nut
Nut
Nut
Nut
NutNut
Nut
Nut
Nut
Nut
Nut
Nut
Bond
Throttle Grip
Master Cylinder
Master Cylinder
Master Cylinder
Master Cylinder
Master Cylinder
Master CylinderMaster Cylinder
Master Cylinder
Master Cylinder
Master Cylinder
Master Cylinder
Master Cylinder
Master Cylinder
“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark
“UP” Mark
Grip
Washer
Washer
Washer
Washer
Washer
WasherWasher
Washer
Washer
Washer
Washer
Washer
Washer

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
