Chapter 7 Memory Design Edit
92 BECS-A88/C88 computerized embroidery machine owner’s manual
the help, and zoom view function.
Needle check orientation front-panel: use for orient “current needle” (needle that
need check and edit).
Needle edit function key: use for switch stitch code, insert needle, delete needle
and move the needle position.
Needle information: Use for information about total stitch amount, serial number、
position and type of current needle.
7.2.2
Document and View Operation
Keep the current pattern to a new document.
Reduce the pattern thus can see the all of the pattern. If the pattern size is
smaller than show scope of the screen, then show the pattern with the actual size.
Enlarge the pattern to 450% to thus look into the detail of the needle
vestige." Current needle" will move the middle position of the screen
automatically.
Enlarge or zoom view. The scaling is 150% every time.
Withdraw the pattern editor function.
Look into online help of the pattern edit operation screen.
7.2.3
Orient Needle
Establish" current needle" arrives some one needle. At the same time, use “＋”to
mark the position of “current needle” in the window of pattern preview. If there is
no “current needle" show in the view, so the system will renew the view
automatically, and show “current needle" in the centre of view.
