DAHAO A88 - Delete Needle; Move Needle

Chapter 7 Memory Design Edit
94 BECS-A88/C88 computerized embroidery machine owner’s manual
7.2.6
Delete Needle
Position the some needle, click
key and can delete that needle.
7.2.7
Move Needle
Position the some needle, click
key and can move that needle.
When press “moves the current needle only”, mean keep absolute position of all
of the stitches behind current stitch. While flick, mean keep opposite position of
current stitch and all of the stitches behind it, that means at the same time of move
the current stitch, absolute position of stitches behind it are all follow to move.
Click
key can change size of distance for each time moving. means
move 0.1mm each time，
means move1mm each time， means move5mm
each time.
While move the needle vestige, will use“＋” to mark new position of stitch trace
automatically in the window of pattern preview. After click“YES”，refer to
modification.
