Chapter 2 Operation Instruction
BECS-A88/C88 computerized embroidery machine owner’s manual 31
its last position along original path. Pull the bar one time, the frame return one
needle step. Pull the bar continuously and the frame will return one needle step
after another continuously. After the frame returns 10 needle steps continuously,
the frame can return continuously even when you release the bar. (This may be
different for different machine types). When the frame return continuously,
release the bar and pull it left again, the frame will stop returning.
The aim of returning is usually to perform patching embroidery. After the
returning stops, push the patching switch of machine head that will perform
patching embroidery to go to the patching mode, and then pull the operation bar
to right and the machine head will start patching embroidery while other heads
don't. When the frame goes to the point where the frame begins to return, other
heads whose patching switches are in normal embroidering mode will start to
embroider.
2-7
Operation Bar and Turn Shaft Button
Operation Bar (Embroidery Bar under the Table)
Stop status: pull the bar right to begin embroidery (including idle running in high
or low speed) and pull the bar left to return (including idle running in high or low
speed)
Running status: pull the bar right to the end to embroider slowly and release to
normal speed and pull the bar left to stop embroidery.
Turn Shaft Button (over the operation bar case, on the right under the table)
To press the button to make the main shaft rotate one cycle and stop at 100±2.5°.
