Chapter 12 Directions on Coiling, Taping and Zigzag Embroidery
168 BECS-A88/C88 computerized embroidery machine owner’s manual
driving the clamp axis. Both the upper and bottom points are set with a proximity
switch to adjust the clamp foot rising height. Neither the upper nor bottom point
has the holding force.
6. (2-phase or 3-phase) stepping motor, driving the embroidery heads by one
motor, 1 proximity switch
In this mode, the clamp foot working height relies on the rotating of the cam
and the clamp foot is raised to the limited height by stepping motor driving the
clamp axis. The upper point is set with a proximity switch to position. The bottom
point is set by parameters. Both the upper and bottom points have the holding
force.
7. Pneumatic motor, separately driving the embroidery heads, without
proximity switch.
In this mode, the clamp foot working height relies on the rotating of the cam
and the clamp foot is raised to the limited height by pneumatic motor driving the
heads separately.
8. The composition chart for special embroidery machine controller
For different control systems, the E854 board takes different software programs
while the E874 board changes the DIP switches. Refer to 12-8.
12-8 Definition Charts of DIP Switches of E874 Boards
Chart 1:
DIP1 Composition Description of the M axis
OFF Manual clutch or without any clutch
ON Automatic clutch
Chart 2：
