Chapter 2 Operation Instruction
32 BECS-A88/C88 computerized embroidery machine owner’s manual
2-8
Patching Switch
Thread Break Detecting Device of 3-Place
There is a switch on every head of machine. When the switch is up, this head is in
normal embroidering mode and when it is in the middle, this head is in patching
mode and when it is down this head is in stop mode.
Thread Break Detecting Device of 2-Place
On every head of the machine, there is a patching switch, and it can be move with
hand to the up, middle or down position, but it is stop only at the middle or down
position. When the switch is pushed to up position, it cannot stay at up position,
and the lamp is red, which hints that this head is in patching mode. In addition,
while thread breaking during embroidering, the lamp is automatically changed
into red and this head is in patching mode. When the switch is at middle position,
this head is in patching mode if the lamp is red, or this head is in normal
embroidering mode if the lamp is green. When the switch is pushed to down
position, the lamp is off, which hints that this head is in stop mode. When the
switch is pushed to middle position from down position, the lamp will be green
and the head is in normal embroidering mode.
2-9
System's Working Statuses
The machine has three working statuses:
Preparation status ⎯⎯ preset parameters; choose embroidery designs
and other preparation work
