ECHO Series Ultrasonic Thickness Gages
71
B-scan Configuration
After the file type is selected, press the F3 – Next key. Then use the arrow keys to select
a number for the Step field, as shown below. Press the F4 – Next key when you are done.
Prefix Start Col
End Col
Note: It is imperative that the starting and ending IDs always have the exact same
number of digits.
