Datalogic Magellan 3300HSi User Manual

Product Reference Guide 161
Physical Properties
Parameter Specification
Dimensions (Scanner only): 6” x 6” x 3.42” (WxHxD)
Weight (Scanner) 1 lb 4.6 oz (0.584kg)
Electrical Parameters
Parameters Specification
AC Power Requirements AC Input: 90-264 VAC, 47~63Hz
AC Power Consumption
Real Power
Operating (Maximum)
9.9 Watts
Operating (Nominal)
3.0 Watts
Sleep mode
2.0 Watts
DC Power Requirements Reference for POT user
Input Voltage
7 to 14 V DC
Operating Current and Power at 12V
DC
Current Power
Maximum Inrush
736mA 8.8 Watts
Maximum Continuous
566mA 6.8 Watts
Nominal Scanner Only
201mA 2.4 Watts
Sleep, Scanner Only
123mA 1.5 Watts
Environmental Parameters
Parameter Specification
Contaminants 
Water and Dust
IP5x
Temperature Ranges:
Operating
32  F to +104  F (0  C to +40  C)
Storage
-40  F to +158  F (-40  C to +70  C)
Ambient Light Indoor
0 - 6,000 lux
Ambient Light Outdoor
0 - 86,100 lux
Humidity
5% to 95% non-condensing
Beeper/Speaker
70-90dBA at a distance of 3’-3” (1 meter)
Vibration
Retail/Office
Other Parameters
Parameter Specification
EAS Support
YES (Checkpoint)

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
