Datalogic Magellan 3300HSi

Product Reference Guide 203
5-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E2'.
• Length of supplemental data including prefix must be 8. Total required
length is 24 for EAN-13 and 19 for EAN-8.
• Examples: addon portion is high
lighted data is underlined.
UPC-A 5-Digit addon ']E00060992011187 ]E212345 '
UPC-E 5-Digit addon ']E00000000998875
]E212345 '
EAN-8 5-Digit addon ']E400210126
]E212345 '
EAN-13 5-Digit
addon
']E01101234567891
]E212345 '
Code 128 Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']C0'.
• length of Supplemental data including prefix is variable but must be at
least 9.
• Examples: addon portion is high
lighted data is underlined.
UPC-A Code 128 addon ']E00060992011187 ]C08100000951 '
UPC-E Code 128 addon 'E00000000998875
]C08100000951 '
EAN-8 Code 128 addon ']E400210126
]C08100000951 '
EAN-13 Code 128 addon ']E01101234567891
]C08100000951 '
Bookland
• The 'Bookland' / ISBN code will be formatted as a vendor specific AIM label.
• Prefix must be ASCII characters ']X0'.
• length of label data including prefix is 13.
• Examples: ']X01234567890'.
Code 39
• Check character must be included in label data.
• Label length including start, stop and check characters and excluding pre-
fix characters must meet requirements imposed by the main scanner's
fixed o
r variable label length control for this symbology type.
• Start and stop characters "*" must be included in label.
•Prefix must be ASCII characters ']A0' or
']A1'.
• Example: '*]A0Code 39.TEST*'.
Codabar
• Check character must be included in label data.
• Label length including check character and excluding prefix characters
mu
st meet requirements imposed by the main scanner's fixed or variable
label length control for this symbology type.
