4 Magellan™ 3300HSi
Error Codes
If an error is detected, the scanner will sound a long low tone (for three sec-
onds) and flash its LED, indicating a failure. When this occurs, remove the top
cover and press the Scanner Push Button to hear the error code. If it is config-
ured to do so, the scanner will sound a series of beeps corresponding to the
error code and/or flash its LED simultaneous to the beeps. The table below
describes what these codes mean and what action should be taken for each.
Installation
For comfortable slide-through scanning, mount the scanner level with the
countertop. Follow these steps for flush installation:
1. Decide the best situation for the scanner by considering...
• Proximity to the user. Verify that checkstand features allow the scanner
to be within easy reach of the user, without interfering with cash draw
-
ers or other equipment.
• Cable routing to and from the scanner: Can cables and connected
devices be routed in such a way as to be protected from damage or tam
-
pering?
• Mounting stability. Avoid placing the scanner in such a way as to subject
it to excess vibration, bumping, spillage, etc.
• Peripheral connections from the scanner, such as a handheld device.
2. The countertop must be modified to accept the scanner. At the time of this
writing, three options are available.
• Figure 3a shows the dimensions for the opening and other details if a
shelf is to be built to support the unit.
• Figure 3b details the cutout dimensions if an adapter fixture holding the
scanner will rest with its rim above the countertop.
NUMBER OF
LED
FLASHES/
BEEPS
ERROR CORRECTIVE ACTION
1
Configuration
Contact Helpdesk for assistance
2
Interface PCB
6
Main PCB
10
Button Error
12
Imager Module
13
Software ID Failure
14
Software Fatal Fault

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
