Datalogic Magellan 3300HSi User Manual

Product Reference Guide 175
Appendix E
Keyboard Function Key Mappings
Keyboard Model Cross Reference
Table 4 summarizes the keyboard models, their defined protocol, scancode set,
and some unique features. The remaining tables in this chapter provide the
function key maps associated with each of the scancode sets.
Table 4. Keyboard Model Cross Reference
Model Type I/F ID
Transmissio
n Protocol
Scancode
Set
Func.
Key
Map
Support
Use
Country
Mode
PC/XT Foreign ALT Mode
Wedge A
PC/XT
Scan Set 1 No No
AT; 
PS/2 25-286; 
PS/2 30-286; 
PS/2 50, 50Z; 
PS/2 60,70,80,90,95 
Foreign ALT Mode
Wedge B
AT/PS2
Scan Set 2 No No
PS/2 25 and 30 
Foreign ALT Mode
Wedge C
AT/PS2
Scan Set 1 No No
PC/XT U.S. Mode
Wedge D
PC/XT
Scan Set 1 Yes No
AT; 
PS/2 25-286; 
PS/2 30-286; 
PS/2 50, 50Z; 
PS/2 60,70,80,90,95 
U.S. Mode + specific 
country support
Wedge E
AT/PS2
Scan Set 2 Yes Yes
PS/2 25 and 30 
U.S. Mode
Wedge F
AT/PS2
Scan Set 1 Yes No
IBM 3xxx Terminals 
(122-key keyboard)
Wedge G
AT/PS2
Scan Set 3 Yes No
IBM 3xxx Terminals 
(102-key keyboard)
Wedge H
AT/PS2
Scan Set 3 Yes No
PS55 5530T with 
JAPANESE DOS (TDOS)
Wedge I
AT/PS2
Japanese
DOS
Yes No
NEC 9801
Wedge J
NEC
9801
NEC 9801 Yes No

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
