6 Magellan™ 3300HSi
LED and Beeper Indicators
The scanner’s beeper sounds and its green LED illuminates to indicate various
functions or errors on the scanner. The tables below list these indications. One
exception to the behaviors listed in the tables is that the scanner’s functions
are programmable, and may or may not be turned on. For example, certain
indications, such as the power-up beep can be disabled using programming
bar code labels.
LED
INDICATION
INDICATION COMMENT
Power-on
indication
Bright green flash
Indicates the scanner has finished all its power up
tests and is now ready for operation.
Good Read
Indication
Bright green flash Indicates a bar code has been read and decoded.
Scanner Ready Constant dim green
The scanner is ready for operation. The LED is also
configurable to off when idle and ready for operation
Sleep Mode
Green LED slowly and contin-
uously changes from off to
dim to off.
The scanner is in Sleep Mode. To wake the scanner up,
move an object in front of its window or press the but-
ton located just beneath the removable top cover of
the unit. This indication is optionally configurable and
may have been programmed to behave differently.
Host Disable
Constant green flash at 1 Hz
(100mS on, 900mS off)
The scanner is disabled due to receiving a disable com-
mand from the POS terminal.
Diagnostics
Varies (see "Error Codes" on
page 1-4 for more informa-
tion)
The LED can provide diagnostic feedback if the scanner
discovers a problem during SelfTest.
Prog. Mode
See Host Disable on page
6 above.
The scanner is in Programming Mode.
