78 Magellan™ 3300HSI
Global Prefix/Suffix
START / END
PROGRAMMING bar codes
Sets up to 20 characters each from the set of ASCII characters or any hex value from 00 to FF. To configure
this feature, scan the “START/END” bar code above to place the unit in Programming Mode, then the “Set
Prefix” or “Set Suffix,” followed by the digits from the Alphanumeric table in Appendix C, representing
your desired character(s). Reference the
section, Global Prefix/Suffix on page 3-155, for more information
on setting this feature. Exit pro
gramming mode by scanning the “START/END” bar code again (scan
“START/END” twice if less than 20 characters have been selected).
DEFAULT SETTING PREFIX: 00 (None)
DEFAULT
SETTING SUFFIX: 0D (CR)
Set Prefix
Set Suffix

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
