Datalogic Magellan 3300HSi

Product Reference Guide 163
Appendix B
Cable Pinouts
Standard Cable Pinouts (Primary Interface Cables)
Pin # RS-232
IBM Port 5B/
9B/17
USB-OEM
USB,
USB
Keyboard,
USB COM
Keyboard
Wedge
DTR PCCLK
CTS
VBUS VBUS
RTS Line B D- D- KBCLK
RxD
TxD Line A D+ D+ PC Data
VCC in VCC in +12V VCC in VCC in
GND GND GND GND GND
KBD
1
2
3
4
5
6
7
8
9
10
