Datalogic Magellan 3300HSi User Manual

190 Magellan™ 3300HSi
6. If installed properly, you should immediately hear an audible signal upon
insertion or removal of a microSD card. Various operations will also be
indicated by the scanner’s good read LED.
microSD Card Removal
1. Push in gently using your finger or thumbnail to disengage and remove the
microSD card. Remember to keep your finger in place atop the card’s edge
to avoid accidentally “launching” the card from the springloaded slot.
2. Reconnect all cables which were disconnected earlier.
CAUTION
The microSD card slot is spring loaded. Keep
your finger lightly in place atop the card until
you are sure it is fully seated in place. See the
illustration on the following page.
Use your finger or thumbnail to push in on
the top edge of the card to be slightly below
flush with the scanner enclosure when
inserting or removing the card. This will
engage/disengage the spring mechanism.
Never insert tools or other foreign objects
into the microSD card slot.
Scanner
microSD Card
Push down past
ush to seat,
then carefully
release
Seated card

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
