Datalogic Magellan 3300HSi User Manual

Product Reference Guide 189
Appendix H
microSD Card
microSDHC Compatibility
At the time of this writing, the microSD card interface for
this product supports SD-Memory Card Specifications/
Part 1. Physical Layer Specification; Version 1.01, but the
processor MCI can communicate with SDHC Cards. For
example, the scanner can perform the functions specified
in this appendix for the SDA 2.0 specification. Both FAT16
and FAT32 formats are supported.
Filenames are limited to the 8.3 file naming format (i.e.,
FILENAME.EXT), and MUST be capitalized.
microSD Card Insertion
1. Read all of these instructions before starting.
2. If you have not already done so, remove the scanner
from its
installed position to allow access to
the microSD card slot.
3. Use a coin or similar blunt object to
lever the top cover from the scan
-
ner, then grasp the lift handles and
carefully lift the unit from the
counter.
4. Ensure there are no other cables
attached to the scanner, then apply power and wait for the reset beep.
5. Lift and rotate the rubber cover to access the card slot, then carefully
insert the microSD card into the slot until it "clicks" into place.
Top Cover
Coin Slot
Lift Handles
Rubber
Cover
microSD Card Slot

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
