Interface Related Features
NOTE
The correct interface cable is generally
included for the reader interface type you
ordered.
At the time of this writing, the reader supports the interfaces listed in Table 2.
Select the desired interface type from the table, then reference the page num-
ber given for the customizable features section associated with each interface.
See Table 3 for a description of each Keyboard Wedge interface type (A through
Y as listed).
Table 2. Interfaces Supported
RS-232 Page Keyboard Wedge
RS-232 Standard
43
Keyboard Wedge A
a
a. Consult Table 3 for more information regarding keyboard interface types.
44
RS-232 Wincor-Nixdorf
43
Keyboard Wedge B
a
44
IBM
Keyboard Wedge C
a
44
IBM 4683 Port 5B
43
Keyboard Wedge D
a
44
IBM 4683 Port 9B
43
Keyboard Wedge E
a
44
IBM 4683 Port 17
43
Keyboard Wedge F
a
44
USB
Keyboard Wedge G
a
44
USB-OEM
43
Keyboard Wedge H
a
44
USB Keyboard
43
Keyboard Wedge I
a
44
USB COM Interface
43
Keyboard Wedge J
a
