Datalogic Magellan 3300HSi

168 Magellan™ 3300HSi
Image Format on page 38
JPG JPG JPG JPG JPG JPG
Image Size on page 39
VGA VGA VGA VGA VGA VGA
Image Brightness on page 40
09 09 09 09 09 09
Image Contrast on page 40
09 09 09 09 09 09
Obey/Ignore Host Commands on
page 45
Obey Obey Obey Obey Obey Obey
Host Transmission Buffers on
page 46
222222
Buad Rate on page 47
9600 9600 9600 9600 9600 9600
Data Bits on page 48
888888
Stop Bits on page 48
111111
Parity on page 48
None None None None None None
Hardware Flow Control on page
49
Disable Disable Disable Disable Disable Disable
Intercharacter Delay on page 50
No Delay No Delay No Delay No Delay No Delay No Delay
Software Flow Control on page
51
Disable Disable Disable Disable Disable Disable
Host Echo on page 52
Disable Disable Disable Disable Disable Disable
Host Echo Quiet Interval on page
53
10 msec 10 msec 10 msec 10 msec 10 msec 10 msec
Signal Voltage: Normal/TTL on
page 54
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
RS-232 Invert on page 55
Disable Disable Disable Disable Disable Disable
Beep on ASCII BEL on page 55
Enable Enable Enable Enable Enable Enable
Beep on Not on File on page 56
Enable Enable Enable Enable Enable Enable
ACK NAK Options on page 57
Disable Disable Disable Disable Disable Disable
ACK Character on page 58
006 006 006 006 006 006
NAK Character on page 58
021 021 021 021 021 021
Retry on ACK NAK Timeout on
page 59
Enable Enable Enable Enable Enable Enable
ACK NAK Timeout Value on page
59
001 001 001 001 001 001
ACK NAK Retry Count on page
60
003 003 003 003 003 003
FEATURE
Aux RS-232
Wincor-
Nixdorf
Single
Cable
USB-
OEM
Keybd
Wedge
