RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
1. Select an Action Type from the drop-down list, using the up/down arrow keys or the mouse scroll
wheel.
Delay is set in milliseconds (ms) with a range of 0-10000ms (10 seconds).
GPO – Set a general purpose output pin to High or Low, or issue a low-going pulse that may
be extended from 100 to 1000 ms.
Input – select an Input Preset from the Change Input To drop-down list.
Network – Send a TCP command to a network device. The IP address and TCP port must
also be entered.
Mute – Select On or Off.
Volume – The master volume control can be Set to a specified value, or it can be incremented
or decremented (Adjust) by a specified value.
Serial – Output serial data on the serial automation port. The data must be entered in the
Data text box.
Set Variable – Enter the Variable Name and set the variable to either True or False.
Run Macro – Run the Macro defined by the Macro Name text box. Touch the text box to open
a virtual keyboard to enter a name.
Note: This application accepts only Latin alphanumeric characters.
Trigger – In the Set field, select which Trigger output (1 through 4) to use. In the To field,
select Pulse, Low, or High. If Pulse is selected, then enter a value in the Width field. The pulse
width can be set between 100ms and 1000ms in 5ms increments.
Run Command – Touch the Cmd field to open a virtual keyboard. Enter a RS20i command to
be run. Any RS20i command defined by the RS20i command API can be executed by this
action. The RS20i API command definitions are in Appendix E, RS20i Command API. Do not
include the leading '@' character, or the trailing carriage return when entering the command as
a Run Command action (they are necessary only for remote serial or network commands).
2. Touch OK when finished, or touch Cancel to cancel this setup.
