RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
Events – See 4.13 Automation Events, page 105.
Buttons – See 4.14 Automation Buttons,
page 106.
Serial – See 4.15 Automation Serial Setup, page 108.
Test – See 4.16 Automation GPIO Test, page 108.
• System
group
System – See 4.8 System Setup, page 86.
Update – See 4.8.1 Update System Software, page 87.
USB – See 4.8.2 USB Save/Restore, pa
ge 89.
Log File – See 4.9.2 Log File, page 97.
Info – See 4.8.4 System Info, page 92.
Network – See 4.10 Network Configuration, page 98.
Access – See 4.8.3 Access Control, p
age 91.
4.2.1 About Input Presets
The RS20i facilitates the process of creating customized audio input presets. While the RS20i comes with
a set of pre-built Input Presets (see table below), an installer normally adds Input Presets, as well as
deletes or changes the existing pre-built presets to fit the requirements of the installation. We use the
term “Input Preset” to mean a selection that includes not only the input source, but additional
configuration items that have been set for that input source. An Input Preset consists of an Input Source,
Input Options, EQ Setup, and an Output Preset, as illustrated below in Figure 17.
Eac
h Input Preset created is given a text name that identifies the preset. The name should be descriptive
to make it easily identifiable by the user. Identifying names are also given to EQ Setups and Output
Presets.
The buttons along the bottom of the RS20i Home screen are the Input Presets that are defined by the
installer for a particular application. If more than 8 input presets are created, then button 8 may be
programmed as the More button which allows access to all available Input Presets through a pop-up
window.
The EQ Setup and Output Presets are named groups of settings. Each Input Preset is assigned an EQ
Setup and an Output Preset. A single EQ Setup may be used for all Input Presets, or unique EQ Setups
may be created and assigned to different Input Presets. The same idea applies to Output Presets.
The RS20i holds a maximum of 20 separate Input Presets, 20 separate EQ Setups and 20 Output
Presets.
Figure 17 shows specifically which confi
guration items are included in an EQ Setup or Output Preset.
Input Options configurations are also shown. Some Input Options are applicable only for specific Input
Sources. The chart displays what Input Source must be selected for each Input Option configuration
item. Global configuration items are those that are not assigned with the Input Preset. Global
configuration includes items such as System Setup, Automation and Network configuration.
Changes in an EQ Setup configuration item are saved with the currently selected EQ Setup. Changes in
an Output Profile configuration item are saved with currently selected Output Profile. Changes in Input
Options are saved with the currently selected Input Preset.
Note: Use this chart in Figure 17 to determine what group a specific configuration
item belongs to, when creating multiple EQ Setups or Output Profiles.
