RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
4.0 Setup Menus
This section describes the RS20i setup menus. The full menu structure of the RS20i is illustrated on the
next five pages. Following that is a detailed explanation of each screen and functionality.
4.1 Navigating the Setup Menus
Select the SETUP button from the Home screen to access the Setup menus. The Setup menus are
intended for use ONLY by a qualified installer. Password protection is highly recommended to prevent
unauthorized access. See 4.8.3 Access Control, page 91, to set the Setup password.
The Setup screen i
s the primary access to many additional sub menus. It is described fully beginning with
section 4.2, page 35
The set
up screen displays the five main setup groups, Input, EQ, Output Preset, Automation, and
System. Each of these groups contains sub menu selections that pertain to that group.
Once you have navigated through sub-menus, selecting the Setup button always returns you to the initial
Setup screen. Selecting the Home button from any menu will return to the Home screen (the main
operator menu).
If SETUP is then reselected, the RS20i returns to the last selected sub-menu.
The Back button works like the back button of an internet browser, and may be used to return through the
history of previously selected sub-menus.
If the
symbol appears on the screen, it indicates that the front panel Volume Control/Adjustment knob
may be used as a navigation tool to scroll through a list of items or text.
In the next sections, we will discuss in detail the options available through the Setup screen.
Note: When using a laptop to VNC into the RS20i, use the up and down arrows to
mimic the scrolling action of the front panel Volume Control knob.
Note: The factory default VNC password is the hyphen “-“ symbol.
