RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
1.0 Operating RS20i
Table 1. How-To Procedures – Operations
Activity Instructions
Turn Power ON Press and release the power button on the front panel. If the unit will not
power up, be sure that the rear panel power switch is ON and the unit is
plugged into a working AC outlet protected by a surge protector. See
Powering ON the RS20i Processor, p
age 13.
Turn Power OFF Press and hold the power button on the front panel for about 2 seconds.
Adjust volume Turn the master volume control knob on the front panel to adjust volume on all
channels. Turn clockwise to increase volume. See Adjusting the Volume
Control, page
15.
Select an input Touch the desired input in the bottom row of the RS20i display. If you do not
see the input you want, see if the right most button displays “More”. If so, tap
the More button for more choices. If the desired input is still not shown, the
RS20i has not been setup for this input.
See The Home Screen, p
age 14.
Identify the selected
input
The current input is highlighted in the bottom row of the RS20i display. More
detail related to this input is shown at the top of the display.
Mute the RS20i Touch the MUTE button. If successful, the MUTE button is highlighted and the
label changes color to red. See Adjusting the Volume Control, pa
ge 15.
Unmute the RS20i Touch the MUTE button. If successful, the button label changes color to white.
Identify muted mode When the RS20i is muted, the MUTE button label is red.
