RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
4.7 Bass Management Setup Procedure
The Bass Management screen is where you set the speaker configuration.
To access the Base Management screen, press:
Setup > Output Prst > BassMan.
Select the Speaker Configuration (that matches your installation) from the drop down on the Bass
Management Setup screen. The channel definitions for each speaker configuration are given in Table 30.
Table 30. Bass Management Speaker Configuration
Speaker
Configu-
ration
Channels
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
2.0
L R
2.1
L R Sw1 Sw2 Sw3 Sw4
3.1
L R C Sw1 Sw2 Sw3 Sw4
4.1
L R Sw1 Ls Rs Sw2 Sw3 Sw4
5.1
L R C Sw1 Ls Rs Sw2 Sw3 Sw4
7.1 h
L R C Sw1 Ls Rs HL HR Sw2 Sw3 Sw4
7.1w
L R C Sw1 Ls Rs Lw Rw Sw2 Sw3 Sw4
9.1hw
L R C Sw1 Ls Rs HL HR Lw Rw Sw2 Sw3 Sw4
7.1
L R C Sw1 Ls Rs Lb Rb Sw2 Sw3 Sw4
9.1h
L R C Sw1 Ls Rs Lb Rb HL HR Sw2 Sw3 Sw4
9.1w
L R C Sw1 Ls Rs Lb Rb Lw Rw Sw2 Sw3 Sw4
11.1 hw
L R C Sw1 Ls Rs Lb Rb HL HR Lw Rw Sw2 Sw3 Sw4
Auro 9.1
L R C Sw1 Ls Rs HL HR HLs HRs Sw2 Sw3 Sw4
Auro
10.1
L R C Sw1 Ls Rs HL HR HLs HRs Sw2 Sw3 Sw4 T
Auro
11.1
L R C Sw1 Ls Rs HL HR HLs HRs Sw2 Sw3 HC T
Auro
11.1
(7+4)
L R C Sw1 Ls Rs Lb Rb HL HR HLs HRs Sw2 Sw3 Sw4
Auro
13.1*
L R C Sw1 Ls Rs Lb Rb HL HR HLs HRs Sw2 Sw3 HC T
*Note: When Auro 13.1 is selected, a checkbox labeled “Phantom HC” appears on the Bass Management
screen, for selecting a 13.1 configuration without
the HC speaker. When selected, the HC channel is
downmixed with HL and HR.
Activate Enable Bass Management on the Bass Management Setup screen. This is the master enable
that turns on all Bass Management functions.
