Setting Description
power switch.
Note: You cannot switch between Dirac1 and Dirac2 filter coefficients without
resetting the RS20i. However, when you switch Dirac Versions, the coefficients
that are already loaded on the RS20i are not deleted from the system. Therefore,
they could still be used after switching back the Dirac Version.
Networked
Linked RS20i
Allows the RS20i to control a second RS20i unit using Ethernet commands. The
second RS20i unit should also be configured to be linked to this unit’s IP
address. Changes in the configuration for Volume, Mute status, and Input
Selections are sent to the linked RS20i unit. Input Selections should be given the
exact same name in order for the input commands to work.
To use this feature select Enable and select IP Addr to enter the IP address
of the other RS20i unit. Once connected, you should see that the volume
control sets the volume for both units.
Feature Key
Touch to open a virtual keyboard for entering the key. This is used to enter an
unlock code when upgrading to optional features.
Monitor
Control the volume of an external monitor. See 4.9.1 Monitor Volume, page 95.
View Log File
Touch the button to switch to the Log File screen. See 4.9.2 Log File, page 97.
Use Cinema
Style Volume
Display
When enabled, the master volume displays as a number from 0.0 to 10.0 in
increments of 0.1, which mimics the volume display common in commercial
cinema equipment.
Relax Analog
Gain Limit
Use if needed to increase the gain on the analog output. It is necessary on some
configurations where bass management is used to downmix channels and levels
are attenuated to avoid digital clipping. Enable only if you notice an exclamation
mark appearing on the master volume control and more gain is required.
VNC: Disable
Hextile Encoding
Selecting this option will improve VNC performance for some VNC clients.
Identity
Touch to open a virtual keyboard for entering text.
The three text fields in the Identify group are used (optionally) for adding
identification or other short text information that is stored with the configuration.
These are labeled “Screen”, “Info1”, and “Info2”. These fields may be used to
enter useful information, such as the unit location or room and installer name.
The text entered in the Screen field is also displayed in the bottom left corner of
the Home screen above the navigation menu. This information can be useful for
verification of the correct RS20i when connecting through VNC.
The Screen, Info1, and Info2 information may be used by a remote theater
management system or other custom application software.
4.9.1 Monitor Volume
When an external powered speaker is connected to the RS20i monitor output, the level can be controlled
using the monitor volume. To adjust the external monitor volume, touch the Monitor button in the System
Setup (2) screen.
