RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
Subwoofer Configuration
The subwoofer configuration option configures the bass management with the number of sub-woofer
channels between 0 and 4.
Table 27. Subwoofer Configuration Options
Subwoofer Configuration Options Number of
Subwoofers
Subwoofer Channel Assignments
No Subs
0 None
Mono
1 to 4 Ch4, Ch13, Ch14, Ch15
LFront/RFront
2 Ch4 - Left Front
Ch13 - Right Front
Front/Back
2 Ch4 - Front
Ch13 - Back
LFront/RFront/Back
3 Ch4 - Left Front
Ch13 - Right Front
Ch14 - Back
LFront/RFront
LBack/RBack
4 Ch4 - Left Front
Ch13 - Right Front
Ch14 - Left Back
Ch15 - Right Back
Note: This option is not available for
speaker configurations with HC (Auro11.1
or Auro13.1).
4.6.1 Speaker Options Configuration Screen
Each speaker or speaker pair can be individually configured in Bass Management by selecting the
speaker icon on the Bass Management screen.
Any Left/Right paired speakers share the same settings, so the configuration needs to be set only on one
of the two. For example, when the Left Front speaker is configured, the Right Front speaker will use that
configuration. Speaker pairs that share configurations are L/R, Ls/Rs, Lb/Rb, HL/HR, HLs/HRs, Lb/Rb,
and Lw/Rw.
Each speaker or speaker pair may display a different set of options. Figure 51 shows Bass Management
Cente
r Speaker Options for a configuration with Subwoofers. Touch the icon of the Center Speaker, in
the Bass Management Setup screen, to access this screen.
