RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
Table 25. Speaker Filter
Control Description
Chan nn
-
+
Channel selection
- previous channel
+ next channel
Pink Noise On/Off
Channel pink noise.
Filters
Enabled/Disabled
Enable or Disable all PEQ filters for all channels.
Constant Q/BW
Constant Q or constant bandwidth.
Filter 1-9
Select filter 1 to 9 to set the filter parameters.
Freq (Hz)
Filter Frequency: 20Hz to 20kHz.
Q
Filter Q: 0.1 to 10.0.
Gain
Filter Gain: -60dB to 12.0dB.
4.6 Bass Management Setup
This section describes how to configure the bass management on the RS20i using the Setup screens.
This assumes that you are familiar with the RS20i bass management features and concepts. If not, you
are encouraged to review topic 4.7.3, Bass Management Theory (page 83) before proceeding with the
setup.
The Bass Ma
nagement configuration, including the Speaker Configuration, is contained within an Output
Preset configuration of the RS20i. The configuration changes made in this screen are applied to the
currently selected Output Preset. Separate Output Presets can be made with different Bass Management
and Speaker Configuration settings.
Bass management balances the bass portion of the audio system based on the speaker configuration.
Sub-bass configurations vary from none up to 4 subwoofers.
