RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
Function Description
Pink Noise Multi
Chan
Enabling allows multiple channels of pink noise to be chosen. When multi-
channel pink noise is disabled, selecting pink noise on one channel
automatically disables pink noise from the other channels.
Digital Volume
Enable
When the Digital Volume is not Enabled, the master volume control will have no
effect on the volume of the Digital Output. Once Digital Volume is Enabled, the
Digital Volume Offset, which may be set from -70.0 dB to 0.0 dB, should be set
to the volume control level that is considered maximum. For example, if the
Digital Volume Offset is set to -15dB, then the digital signal attenuates as
expected when the master volume control is set below -15dB. The digital signal
volume will not increase if the volume control goes above the Digital Volume
Offset.
Digital Volume
dB Offset
Adjust by selecting it and using the Volume Control knob. The volume level is
in effect only if the enable/disable box is enabled (blue).
Note: The Pink Noise and Mute settings are temporary and not saved with the
configuration.
Note: Channels 1 through 16 on this screen refer to the input channels. In cases
where the input is routed to a different output channel, the control represents
only the input channel path. The same is true if the channel is routed to more
than one output in a crossover configuration. For example, if L (Ch1) is routed
to output channels 1 (Left-H) and 2 (Left-L), then if Ch1 is inverted the signal
will be inverted on both output channels 1 and 2.
4.5 Output Preset
The Output Preset screen allows you to select and/or configure the Output Preset for the current Input
Preset.
To access Output Preset Setup:
