Maintenance
Milk sampler
94897201.pdf2007-12-18
2
2. Remove the silicon hose from the sample
tube and hold the silicone hose.
3-4
Remove the
silicone hose
from the hole.
3. Slowly rewind the silicone hose onto the
tube wheel using a finger.
4. Pull the silicone hose and remove it from
the hole.
Note: Keep finger on the tube wheel to
prevent it revolving too fast. If you let the
tube wheel rotate freely, the spring will be
damaged and must then be replaced.
5. Return the wheel slowly to the start
position.
6. To fit a new silicone hose onto the tube
wheel, turn the tube wheel 8 times
clockwise.
7. Push the silicone hose through the hole
in the wheel.
8. Allow the spring to rewind the silicone
hose on to the wheel.
144(198)
