Operation
DeLaval voluntary milking system VMS
94897201.pdf2007-12-18
The tasks that are carried out during the
manual milking procedure, for example
identification of a cow, are described as
separate tasks in more detail in the
following sections.
Stall and feeding functions
Stall and feeding functions include opening
and closing gates, dispensing feed,
adjusting the manger, controlling the rear
plate and using the floor cleaning. These
functions are performed using the Stall
control window.
Note: Ensure that the station is in manual
mode.
To display the Stall control window:
Working modeService mode
1. Set the service switch in service mode.
1. Press the VMS button in the top right
corner. This will display the VMS menu.
2. Press the Stall Control button.
The buttons are used in the following way:
Stall control, left side-entry station
Open and Close buttons: opens or closes
the entrance and the exit gates.
Release (Rear Plate): releases the rear
plate against the back legs of the cow to
make the teat attachment work properly.
Pull Back (Rear plate): retracts the rear
plate to the upright position.
Long Cow or, Short Cow (Manger
Position): adjusts the position of the
manger. Short Cow moves the manger
towards the cow, Long Cow further away.
Feeder 50 gr: dispenses 50 gram feed into
the manger. (The number of buttons that
can be used depends on the number of
dispensers that are installed and in use.)
Floor Cleaner: flushes the floor with water.
Close Stall Control: closes the window.
59(198)
