Operation
DeLaval voluntary milking system VMS
94897201.pdf2007-12-18
Control Status Meaning Control Status Meaning
Alarm lamp ON User notification concerning the tank system. The VMS
system is still operating.
Alarm lamp ON User notification concerning the tank system. The VMS
system is still operating.
Flashing Stop alarm. The VMS system has been stopped.Flashing Stop alarm. The VMS system has been stopped.
OFF No alarm.OFF No alarm.
Milking lamp ON Milk can be delivered to the tank; milk in tank should be
cooled.
Milking lamp ON Milk can be delivered to the tank; milk in tank should be
cooled.
Flashing Milk can be delivered to the tank; milk in tank should not be
cooled (tank is probably empty).
Flashing Milk can be delivered to the tank; milk in tank should not be
cooled (tank is probably empty).
Flashing
fast
Milk cannot be delivered to the tank. (An alarm will be issued if
this state is held for too long.)
Flashing
fast
Milk cannot be delivered to the tank. (An alarm will be issued if
this state is held for too long.)
OFF No milking takes place.OFF No milking takes place.
Pick-up button/lamp ON Button has been pressed to notify the VMS system that tank
emptying is about to take place. The VMS system has
stopped, or has just finished, conveying milk to the tank. Inlet
to tank (milk valve) has been closed.
Pick-up button/lamp ON Button has been pressed to notify the VMS system that tank
emptying is about to take place. The VMS system has
stopped, or has just finished, conveying milk to the tank. Inlet
to tank (milk valve) has been closed.
Flashing Button has been pressed to notify the VMS system that tank
emptying is about to take place. Milking session is still in
progress and the VMS system will convey milk to the tank
when the session is complete or the delay has elapsed. Inlet
to tank has not yet been closed.
Flashing Button has been pressed to notify the VMS system that tank
emptying is about to take place. Milking session is still in
progress and the VMS system will convey milk to the tank
when the session is complete or the delay has elapsed. Inlet
to tank has not yet been closed.
OFF Button has not been pressed.OFF Button has not been pressed.
Pick-up valve
button/lamp
ON The pick-up valve is open and the tank is (probably) being
emptied.
Pick-up valve
button/lamp
ON The pick-up valve is open and the tank is (probably) being
emptied.
Flashing The pick-up valve is open and the tank is (probably) being
emptied. Milking session is still in progress and the VMS
system will convey milk to the tank when the session is
complete or the delay has elapsed. Inlet to tank has not yet
been closed.
Flashing The pick-up valve is open and the tank is (probably) being
emptied. Milking session is still in progress and the VMS
system will convey milk to the tank when the session is
complete or the delay has elapsed. Inlet to tank has not yet
been closed.
OFF Pick-up valve is closed.OFF Pick-up valve is closed.
Pick-up valve button is used to open the pick-up valve.Pick-up valve button is used to open the pick-up valve.
Cleaning lamp ON Tank cleaning is running; not possible to convey milk to tank.Cleaning lamp ON Tank cleaning is running; not possible to convey milk to tank.
OFF Tank cleaning is not running.OFF Tank cleaning is not running.
To empty the tank, carry out the steps
below. If necessary, see the tank manual for
additional instructions on how to operate the
tank.
1. Press the pick-up button on the MRC
keypad.
2. Stir the milk for at least two minutes.
3. When the stirring is complete, switch off
the cooling.
74(198)
