Replacing Consumables

225

Remove the orange protective covering of the

installed drum cartridge and discard it.

Close the inner cover.

Rotate the lock levers to secure the inner cover

while pressing the cover with the other hand.

Remove the cleaning rod from the backside of

the front cover.
