13 Maintenance

242

2

Press the power switch to the [ ] position to

switch the power off.

3

Raise the latch of the right hand cover and open

the cover.

4

Open the front cover.

5

Rotate the lock levers of the inner cover to open

it.

6

Grasp the handle on the front of the transfer

belt unit.
