Cleaning the Machine
243
7
Pull out the transfer belt unit until the line on
the unit becomes completely visible.
8
Grasp the handles on the top of the transfer
belt unit. Pull out the unit to remove it from
the machine.
Note • Do not hold the parts shown in the illustration.
9
Slide the blue tab back-and-forth five times.
Note • Be careful not to touch the fusing unit. It can
burn your fingers.
10
Grasp the handles on top of the transfer belt
unit.
Note • Do not hold the sides of the transfer belt unit.
It may degrade print quality.
To Next Page
