Chapter 4 Parameters|
4-126 Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
07.34 Torque Compensation (Motor 3) Unit: 0.1
Settings 0.0 to 10.0 Factory Setting: 0.0
07.35 Slip Compensation (Used without PG) (Motor 3) Unit: 0.01
Settings 0.00 to 10.00 Factory Setting: 0.00
07.36 Motor Line-to-line Resistance R1 (Motor 3) Unit: 1
Settings
0 to 65535 mΩ
Factory Setting: 0
07.37 Motor Rated Slip (Motor 3) Unit: 0.01
Settings 0.00 to 20.00Hz Factory Setting: 3.00
07.38 Motor Pole Number (Motor 3) Unit: 1
Settings 2 to 10 Factory Setting: 4
The motor 0 to motor 3 can be selected by setting the multi-function input terminals MI3~MI6
(Pr.04.05 to Pr.04.08) to 27 and 28.
