Appendix D How to Use PLC Function|
D-4 Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
Device Y
ID 0 1 2 3 4
Terminals of AC
Drives
RY
MO1 -- -- --
Relay Card-2C
(EME-DR2CA)
-- --
RY2 RY3 --
Relay Card-3A
(EME-R3AA)
-- --
RY2 RY3 RY4
3IN/3OUT Card
(EME-D33A)
-- -- MO2 MO3 MO4
D.2.3 WPLSoft Installation
Download PLC program to AC drive: Refer to D.3 to D.7 for writing program and download
the editor (WPLSoft V2.09) at DELTA website
http://www.delta.com.tw/product/em/plc/plc_software.asp.
D.2.4 Program Input
