Chapter 4 Parameters|
Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12 4-29
Parameter Explanation Settings
Factory
Setting
Customer
23: Quick Stop (Only for VFD*E*C models)
24: Download/execute/monitor PLC Program
(PLC2) (NOT for VFD*E*C models)
25: Simple position function
26: OOB (Out of Balance Detection)
27: Motor selection (bit 0)
28: Motor selection (bit 1)
Group 12: Analog Input/Output Parameters for Extension Card
Parameter Explanation Settings
Factory
Setting
Customer
0: Disabled
1: Source of the 1st frequency
2: Source of the 2nd frequency
3: PID Set Point (PID enable)
4: Positive PID feedback
12.00
AI1 Function
Selection
5: Negative PID feedback
0
0: ACI2 analog current (0.0 ~ 20.0mA)
12.01
AI1 Analog Signal
Mode
1: AVI3 analog voltage (0.0 ~ 10.0V)
1
12.02
Min. AVI3 Input
Voltage
0.0 to 10.0V 0.0
12.03
Min. AVI3 Scale
Percentage
0.0 to 100.0% 0.0
12.04
Max. AVI3 Input
Voltage
0.0 to 10.0V 10.0
12.05
Max. AVI3 Scale
Percentage
0.0 to 100.0% 100.0
12.06
Min. ACI2 Input
Current
0.0 to 20.0mA 4.0
12.07
Min. ACI2 Scale
Percentage
0.0 to 100.0% 0.0
