Delta VFD-E User Manual

Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12 B-1
Appendix B Accessories
B.1 All Brake Resistors & Brake Units Used in AC Motor Drives
Note: Please only use DELTA resistors and recommended values. Other resistors and values will
void Delta’s warranty. Please contact your nearest Delta representative for use of special resistors.
The brake unit should be at least 10 cm away from AC motor drive to avoid possible interference.
Refer to the “Brake unit Module User Manual” for further details.
Applicable
Motor
Voltage
hp kW
AC Drive Part No.
Full
Load
Torque
KG-M
Equivalent
Resistor Value
(recommended)
Brake Unit Part
No. and
Quantity
Brake Resistors
Part No. and
Quantity
Brake
Torque
10%ED
Min. Equivalent
Resistor Value
for each AC
Motor Drive
VFD002E11A/11C/11P
200W 250Ω
BUE-20015 1 BR200W250 1 320
200Ω
0.25 0.2
VFD002E11T
0.110
200W 250Ω
BR200W250 1 320
200Ω
VFD004E11A/11C/11P
200W 250Ω
BUE-20015 1 BR200W250 1 170
100Ω
0.5 0.4
VFD004E11T
0.216
200W 250Ω
BR200W250 1 170
100Ω
115V Series
1 0.75 VFD007E11A/11C/11P 0.427
200W 150Ω
BR200W150 1 140
80Ω
VFD002E21A/21C/21P/23A
23C/23P
200W 250Ω
BUE-20015 1 BR200W250 1 320
200Ω
0.25 0.2
VFD002E21T/23T
0.110
200W 250Ω
BR200W250 1 320
200Ω
VFD004E21A/21C/21P/23A
/23C/23P
200W 250Ω
BUE-20015 1
BR200W250
1 170
100Ω
0.5 0.4
VFD004E21T/23T
0.216
200W 250Ω
BR200W250
1 170
100Ω
VFD007E21A/21C/21P/23A
/23C/23P
200W 150Ω
BUE-20015 1 BR200W150 1 140
80Ω
1 0.75
VFD007E21T/23T
0.427
200W 150Ω
BR200W150 1 140
80Ω
VFD015E21A/21C
300W 85Ω
- 125
40Ω
VFD015E23T
300W 85Ω
- 125
80Ω
2 1.5
VFD015E23A/23C/23P
0.849
300W 85Ω
BUE-20015 1 - 125
80Ω
3 2.2
VFD022E21A/21C/23A/23C
1.262
600W 50Ω
- 120
40Ω
5 3.7
VFD037E23A/23C
2.080
600W 50Ω
- 107
40Ω
7.5 5.5
VFD055E23A/23C
3.111
800W 37.5Ω
- 85
34Ω
10 7.5
VFD075E23A/23C
4.148
1200W 25Ω
- 90
24Ω
15 11 VFD110E23A/23C 6.186
1200W 8Ω
BR1K2W008
2 100
8Ω
230V Series
20 15 VFD150E23A/23C 8.248
3000W 10Ω
BR1K5W005
2 119
10Ω
VFD004E43A/43C/43P
300W 400Ω
BUE-40015 1 BR300W400
1 400
400Ω
0.5 0.4
VFD004E43T
0.216
300W 400Ω
BR300W400
1 400
400Ω
VFD007E43A/43C/43P
300W 400Ω
BUE-40015 1 BR300W400 1 200
200Ω
1 0.75
VFD007E43T
0.427
300W 400Ω
BR300W400 1 200
200Ω
VFD015E43A/43C/43P
400W 300Ω
BUE-40015 1 BR200W150 2 140
160Ω
2 1.5
VFD015E43T
0.849
400W 300Ω
BR200W150 2 140
160Ω
3 2.2
VFD022E43A/43C
1.262
600W 200Ω
BR300W400 2 140
140Ω
5 3.7
VFD037E43A/43C
2.080
750W 140Ω
- 125
96Ω
7.5 5.5
VFD055E43A/43C
3.111
1100W 96Ω
- 120
96Ω
10 7.5
VFD075E43A/43C
4.148
1500W 69Ω
- 125
69Ω
15 11
VFD110E43A/43C
6.186
2000W 53Ω
- 108
53Ω
20 15
VFD150E43A/43C
8.248
4800W 32Ω
BR1K2W008 4 151
31Ω
25 18.5
VFD185E43A/43C
10.281
4800W 32Ω
BR1K2W008 4 121
31Ω
460V Series
30 22
VFD220E43A/43C
12.338
4800W 32Ω
BR1K2W008 4 100
31Ω

Delta VFD-E Specifications

General

Protection Features	IP20
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F, Sensorless Vector
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Analog Inputs	2 (0-10V, 4-20mA)
Analog Outputs	1 (0-10V)
Communication Interface	RS-485
Output Voltage	3-phase, equal to input voltage
Power Range	0.4kW to 7.5 kW
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Cooling Method	Fan cooled
Digital Outputs	1 relay output
