Delta VFD-E User Manual

Chapter 4 Parameters|
Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12 4-21
Parameter Explanation Settings
Factory
Setting
Custome
r
07.26
Motor No-Load
Current (Motor 2)
0%FLA to 99% FLA 0.4*FLA
07.27
Torque
Compensation
(Motor 2)
0.0 to 10.0 0.0
07.28
Slip Compensation
(Used without PG)
(Motor 2)
0.00 to 10.00 0.00
07.29
Motor Line-to-line
Resistance R1
(Motor 2)
0~65535 mΩ
0
07.30
Motor Rated Slip
(Motor 2)
0.00 to 20.00 Hz 3.00
07.31
Motor Pole Number
(Motor 3)
2 to 10 4
07.32
Motor Rated Current
(Motor 3)
30 %FLA to 120% FLA FLA
07.33
Motor No-Load
Current (Motor 3)
0%FLA to 99% FLA 0.4*FLA
07.34
Torque
Compensation
(Motor 3)
0.0 to 10.0 0.0
07.35
Slip Compensation
(Used without PG)
(Motor 3)
0.00 to 10.00 0.00
07.36
Motor Line-to-line
Resistance R1
(Motor 3)
0~65535 mΩ
0
07.37
Motor Rated Slip
(Motor 3)
0.00 to 20.00 Hz 3.00
07.38
Motor Pole Number
(Motor 3)
2 to 10 4
Group 8 Special Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
08.00
DC Brake Current
Level
0 to 100% 0

Delta VFD-E Specifications

General

Protection Features	IP20
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F, Sensorless Vector
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Analog Inputs	2 (0-10V, 4-20mA)
Analog Outputs	1 (0-10V)
Communication Interface	RS-485
Output Voltage	3-phase, equal to input voltage
Power Range	0.4kW to 7.5 kW
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Cooling Method	Fan cooled
Digital Outputs	1 relay output
