Delta VFD-E

Appendix B Accessories|
B-14 Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
Inductance (mH)
kW HP
Fundamental
Amps
Max.
continuous
Amps
3% impedance 5% impedance
5.5
7.5 25 37.5 0.5
1.2
7.5
10 35 52.5 0.4
0.8
11
15 55 82.5 0.25
0.5
15
20 80 120 0.2
0.4
460V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max.
continuous
Amps
3% impedance 5% impedance
0.4 1/2 2 3 20 32
0.75
1
4 6 9 12
1.5
2
4 6 6.5 9
2.2
3
8 12 5 7.5
3.7
5
12 18 2.5 4.2
5.5
7.5
18 27 1.5 2.5
7.5
10
18 27 1.5 2.5
11
15
25 37.5 1.2 2
15
20
35 52.5 0.8 1.2
18.5
25
45 67.5 0.7 1.2
22
30
45 67.5 0.7 1.2
B.4.3 Applications
Connected in input circuit
Application 1
Question
When more than one AC motor drive is
connected to the same mains power, and one
of them is ON during operation.
When applying power to one of the AC motor
drive, the charge current of the capacitors
may cause voltage dip. The AC motor drive
may be damaged when over current occurs
during operation.
