Delta VFD-E User Manual

Appendix B Accessories|
B-12 Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A) Bussmann P/N
VFD055E43A/43C 14 13 30 JJS-30
VFD075E23A/23C 34 33 60 JJN-60
VFD075E43A/43C 19 18 40 JJS-40
VFD110E23A/23C 48 45 100 JJN-100
VFD110E43A/43C 26 24 50 JJS-50
VFD150E23A/23C 70 65 150 JJN-150
VFD150E43A/43C 35 32 70 JJN-70
VFD185E43A/43C 41 38 80 JJN-80
VFD220E43A/43C 49 45 100 JJN-100
B.4 AC Reactor
B.4.1 AC Input Reactor Recommended Value
230V, 50/60Hz, 1-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3~5% impedance
0.2 1/4 4 6 6.5
0.4 1/2 5 7.5 3
0.75 1 8 12 1.5
1.5 2 12 18 1.25
2.2 3 18 27 0.8
230V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3%
impedance
5%
impedance
0.2 1/4 2 3 9 20
0.4 1/2 2 3 6.5 12
0.75 1 4 6 3 6.5
1.5 2 8 12 1.5 3

Delta VFD-E Specifications

General

Protection Features	IP20
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F, Sensorless Vector
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Analog Inputs	2 (0-10V, 4-20mA)
Analog Outputs	1 (0-10V)
Communication Interface	RS-485
Output Voltage	3-phase, equal to input voltage
Power Range	0.4kW to 7.5 kW
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Cooling Method	Fan cooled
Digital Outputs	1 relay output
