Delta VFD-E

Chapter 4 Parameters|
4-14 Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
Parameter Explanation Settings
Factory
Setting
Customer
04.11
Min AVI Voltage 0.0 to 10.0V
0.0
04.12
Min AVI Frequency
0.0 to 100.0%
0.0
04.13
Max AVI Voltage 0.0 to 10.0V
10.0
04.14
Max AVI Frequency 0.0 to 100.0%
100.0
04.15
Min ACI Current 0.0 to 20.0mA
4.0
04.16
Min ACI Frequency
0.0 to 100.0%
0.0
04.17
Max ACI Current 0.0 to 20.0mA
20.0
04.18
Max ACI Frequency 0.0 to 100.0%
100.0
0: ACI
04.19 ACI/AVI2 Selection
1: AVI2
0
04.20
Min AVI2 Voltage 0.0 to 10.0V
0.0
04.21
Min AVI2 Frequency
0.0 to 100.0%
0.0
04.22
Max AVI2 Voltage 0.0 to 10.0V
10.0
04.23
Max AVI2
Frequency
0.0 to 100.0%
100.0
Read only
Bit0=1:MI1 used by PLC
Bit1=1:MI2 used by PLC
Bit2=1:MI3 used by PLC
Bit3=1:MI4 used by PLC
Bit4=1:MI5 used by PLC
Bit5=1:MI6 used by PLC
Bit6=1: MI7 used by PLC
Bit7=1: MI8 used by PLC
Bit8=1: MI9 used by PLC
Bit9=1: MI10 used by PLC
04.24 The Digital Input
Used by PLC
(NOT for VFD*E*C
models)
Bit10=1: MI11 used by PLC
##
