DEWESOFT SIRIUS Series User Manual

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


USB 
Front: 4x USB 3.0 
Rear: 2x USB 2.0 
Ethernet 
Front: 1x GLAN (RJ45) 
Back: 1x GLAN (RJ45), 1x WLAN (RP-SMA Female Jack) 
EtherCAT® 
1x EtherCAT® 100 Mbps Full Duplex, 8-pin LEMO female 
Synchronisation 
2x SIRIUS® SYNC 
Video 
1x DVI-D 
GPS (option) 
10 Hz or 100 Hz or 100 Hz + RTK 
GPS display (option) 
External on DSUB-9 female connector + remote power on 
Power out 
Switched input supply on 2-pin LEMO female (max. 8 A) 
Power 
Power supply 
9 - 36 V DC 
Power consumption 
Typ. 35 W (Max. 56 W) 
Environmental 
Operating Temperature 
-10 to 50 °C 
Storage Temperature 
-40 to 85 °C 
Humidity 
5 % to 95 % RH non-condensing at 50 °C 
IP rating 
IP20 
Shock & Vibration 
Vibration sweep sinus (EN 60068-2-6:2008) 
Vibration random (EN 60721-3-2: 1997 - Class 2M2) 
Shock (EN 60068-2-27:2009) 
MIL-STD-810D 
Physical 
Dimensions 
266 x 139 x 109 mm 
Weight 
3.0 kg 


Important 
For Analog inputs detailed specifications please see chapters: “ STGMv3: Specifications ”, “ STGM”           
for connection to DSUB-9. 
For Digital inputs detailed specifications please see chapters: “ STGM+ (Counter)” and “ General            
counter specifications ”. 

 
SIRIUS
®
V20-1 101 / 336  

DEWESOFT SIRIUS Series Specifications

General

Category	Data Loggers
Manufacturer	DEWESOFT
Series	SIRIUS
Resolution	24-bit
Interface	USB, EtherCAT
Software	DEWESoft X
Channels	Expandable
Sampling Rate	Up to 200 kS/s per channel
Input Types	Voltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range	±10 V, ±200 V
Isolation	Channel-to-channel and channel-to-ground
Connectivity	Ethernet, USB
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Power Supply	10 to 30 V DC
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
Analog Inputs	Yes, depending on module configuration
