5.2.4. Isolated version: EtherCAT®
The basic concept is the same as on the isolated USB version but the EtherCAT® slices do not have CAN
or analog-output. They also do not have a separate sync-connector, since the synchronisation is done via
the EtherCAT® protocol.
EtherCAT® Motherboard
Warning
Be careful with voltages >25 VAC or >35 VDC! These voltages are already high enough in order
to get a perilous electric shock by touching the wiring.
