SIRIUS
®
TECHNICAL REFERENCE MANUAL
4.6.2. SIRIUS-SBOXwe: Front side
SIRIUS-SBOXwe Front side
Name
Description
PWR LED light
Green when Power is available and switch on
PWR switch
Power On rocker switch
GPS
Connection for external GPS display, PPS, Remote ON
ETH
1x GLAN Ethernet, RJ45 connector, Watertight push-pull
USB 2.0
3x USB 2.0 connector, Watertight push-pull
SIRIUS
®
V20-1 62 / 336
