DEWESOFT SIRIUS Series User Manual

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


5.23. Analog out option 
The analog output option adds 8 analog output channels (BNC connectors) to the SIRIUS® slices and                
supports 4 different operation modes: 
● Standalone digital signal conditioner 
● Function Generator (Modal/Shaker control) 
● File replay to analog 
● Channel Output 

Important 
For SIRIUS Function Generator option a software licence is required! 


Important 
● The Analog output Function generator option is only available with USB connection. 
● The Analog out Signal conditioning option in HD - High Density SIRIUS slice is possible for                
the first 8 channels only. 
● The Multi modules have the analog out channels per default on the front side 
connectors. When you order a Multi module with additional analog out OPTION, the front              
side analog out will NOT be connected – only the analog out of the rear BNC connectors. 
 
SIRIUS
®
V20-1 253 / 336  

DEWESOFT SIRIUS Series Specifications

General

Category	Data Loggers
Manufacturer	DEWESOFT
Series	SIRIUS
Resolution	24-bit
Interface	USB, EtherCAT
Software	DEWESoft X
Channels	Expandable
Sampling Rate	Up to 200 kS/s per channel
Input Types	Voltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range	±10 V, ±200 V
Isolation	Channel-to-channel and channel-to-ground
Connectivity	Ethernet, USB
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Power Supply	10 to 30 V DC
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
Analog Inputs	Yes, depending on module configuration
