SIRIUS
®
TECHNICAL REFERENCE MANUAL
4.8.1. SIRIUS-SBOXse: Specifications
Computer
Processor
Intel® Core™ i3; 2x 2.3 GHz base; 4 threads
Memory
8 GB (optional up to 32 GB)
Storage
Non-removable M2 500GB (1 TB as option)
Interfaces and options
USB Front
4x USB 3.0
Ethernet
2x GLAN (RJ45) 2x front, 1x WLAN (RP-SMA Female Jack)
EtherCAT®
1x EtherCAT® 100 Mbps Full Duplex, 8-pin LEMO female
Synchronisation
2x SIRIUS® SYNC
Video
1x HDMI
GPS (option)
10 Hz or 100 Hz or 100 Hz + RTK
GPS display (option)
External on DSUB-9 female connector + remote power on
Physical
Weight
0.76 kg
SIRIUS
®
V20-1 68 / 336
